Mellanox LinkX MFS1S50-H003E Network Cable

Open Box products are in original manufacturer condition, include accessories, and most carry the manufacturer warranty. Manuals and software might not be included, but can usually be downloaded from the manufacturer. These items can be in the original manufacturer box or repackaged for protection during shipping.

Mellanox MFS1S50-H003E 200Gb/s to 2x100Gb/s Active Splitter Fiber Cable - 9.84 ft Fiber Optic Network Cable for Network Device, Switch - First End: 1 x QSFP28 Network - Second End: 2 x QSFP28 Network - 200 Gbit/s - Splitter Cable - Black

Mellanox's LinkX MFS1S50-H003E active splitter optical cable for InfiniBand HDR is a cost-effective solution for high bandwidth fabrics, extending the benefits of Mellanox's high-performance InfiniBand adapters and switches.

This Mellanox QSFP28 to 2xQSFP28 cable is an assembly of 4 full-duplex lanes, where each lane is capable of transmitting data at rates up to 50Gb/s per direction, providing an aggregated rate of 200Gb/s. The MFS1S50 provides connectivity between systems using an HDR QSFP28 switch port on one end and two HDR100 HCA QSFP28 ports on the other. The MFS1S50 connects the data signals from each of 2 lanes on the single QSFP28 end to 2 lanes on each of the two QSFP28 ends on the HDR100 multiport side. Each QSFP28 cage comprises an EEPROM providing product information that can be read by the host system. Mellanox certified cables are 100% tested on Mellanox's equipment to ensure interoperability and the best end-to-end performance. Mellanox's active optical cables are designed to create the smallest environmental footprint.

Mellanox optical solutions provide short, medium and long range scalability for all topologies, utilizing innovative optical technologies to enable extremely high signal integrity and reliability. Rigorous cable production testing ensures the best out-of-the-box installation experience, performance and durability

Model Number	MFS1S50-H003E
Product Line	LinkX
Product Name	Mellanox LinkX MFS1S50-H003E Network Cable
Product Type	Network Cable
Cable Type	Fiber Optic
Cable Characteristic	Splitter Cable
Cable Length	9.84 ft
Connector on First End	1 x QSFP28 Network
Connector on Second End	2 x QSFP28 Network
Features	Durable
Device Supported	Switch
Data Transfer Rate	200 Gbit/s
Color	Black Pull Tab
Environmentally Friendly	Yes
Environmental Certification	RoHS-6
