Intel AT8076806419 Core Ultra 9 285K SRQD5 Desktop Processor

Open Box products are in original manufacturer condition, include accessories, and most carry the manufacturer warranty. Manuals and software might not be included, but can usually be downloaded from the manufacturer. These items can be in the original manufacturer box or repackaged for protection during shipping.

Intel AT8076806419 Core Ultra 9 285K SRQD5 Desktop Processor - 24-core - 36 MB Cache - LGA-1851 Socket - 3.7 GHz Base Frequency

The Intel Core Ultra 9 processor offers performance with a clock speed of 2.3 GHz and the capability to boost up to 5.1 GHz. This processor is built on Smart Cache technology, featuring 24 MB of cache memory for efficiency in data processing. With 16 cores and 22 threads, it manages multi-threaded applications, ensuring smooth operation across demanding tasks. Integrated Intel Arc Graphics elevate the visual experience, supporting up to 7680 x 4320 @ 60 Hz (HDMI) resolution. The ability to handle quad display setups means improved multitasking capabilities. Additional features, such as Intel Quick Sync Video and advanced security technologies, enhance this processor, making it a versatile choice for professionals and enthusiasts alike.

Model Number	AT8076806419
Product Name	Intel AT8076806419 Core Ultra 9 285K SRQD5 Desktop Processor
Product Type	Processor
Processor	9th Generation Intel Core Ultra 9 285K
Total Cores	24
Number of Performance-cores	8
Number of Efficient-cores	16
Total Threads	24
Maximum Turbo Frequency	5.7 GHz
Intel Thermal Velocity Boost Frequency	5.7 GHz
Intel Turbo Boost Maximum Technology 3.0 Frequency	5.6 GHz
Performance-core Maximum Turbo Frequency	5.5 GHz
Efficient-core Maximum Turbo Frequency	4.6 GHz
Performance-core Base Frequency	3.7 GHz
Efficient-core Base Frequency	3.2 GHz
Cache	36 MB Intel Smart Cache
Total L2 Cache	40 MB
Processor Base Power	125 Watts
Maximum Turbo Power	250 Watts
Intel Deep Learning Boost (Intel DL Boost) on CPU	Yes
AI Software Frameworks Supported by CPU	OpenVINO, WindowsML, DirectML, ONNX RT, WebNN
CPU Lithography	TSMC N3B
Maximum Memory Size (Dependent on Memory Type)	256 GB
Memory Types	Up to DDR5 6400 MT/s
Maximum Number of Memory Channels	2
ECC Memory Supported	Yes
GPU Name	Intel Graphics
Graphics Base Frequency	300 MHz
Graphics Maximum Dynamic Frequency	2 GHz
GPU Peak TOPS (Int8)	8
Graphics Output	eDP1.4b, DP 2.1 UHBR20, HDMI 2.1 FRL
Xe-cores	4
Maximum Resolution (HDMI)	4096 x 2304 @ 60 Hertz (HDMI 2.1 TMDS), 7680 x 4320 @ 60 Hertz (HDMI 2.1 FRL)
Maximum Resolution (DP)	7680 x 4320 @ 60 Hertz
Maximum Resolution (eDP - Integrated Flat Panel)	3840 x 2400 @ 120 Hertz
DirectX Support	12
OpenGL Support	4.5
OpenCL Support	3
H.264 Hardware Encode/Decode	Yes
H.265 (HEVC) Hardware Encode/Decode	Yes
AV1 Encode/Decode	Yes
Intel Quick Sync Video	Yes
Number of Displays Supported	4
Intel Deep Learning Boost (Intel DL Boost) on GPU	Yes
AI Software Frameworks Supported by GPU	OpenVINO, WindowsML, DirectML, ONNX RT, WebGPU
NPU Name	Intel AI Boost
NPU Peak TOPS (Int8)	13
Sparsity Support	Yes
Windows Studio Effects Support	Yes
AI Software Frameworks Supported by NPU	OpenVINO, WindowsML, DirectML, ONNX RT, WebNN
Direct Media Interface (DMI) Revision	4
Maximum Number of DMI Lanes	8
Intel Thunderbolt 4	Yes
Scalability	1S Only
PCI Express Revision	5.0 and 4.0
PCI Express Configurations	Up to 1x16+2x4, 2x8+2x4, 1x8+4x4
Maximum Number of PCI Express Lanes	24
Advanced Technologies	Intel Gaussian & Neural Accelerator: 3.5, Intel Thread Director, Intel Speed Shift Technology, Intel Thermal Velocity Boost, Intel Turbo Boost Maximum Technology 3.0, Intel Turbo Boost Technology: 2.0, Intel 64 , Instruction Set: 64-bit, Instruction Set Extensions : Intel SSE4.1, Intel SSE4.2, Intel AVX2, Idle States, Enhanced Intel SpeedStep Technology, Thermal Monitoring Technologies, Intel Volume Management Device (VMD)
Security & Reliability	Intel vPro Enterprise, Intel Threat Detection Technology (TDT), Intel Active Management Technology (AMT), Intel Standard Manageability (ISM), Intel Remote Platform Erase (RPE), Intel One-Click Recovery, Intel Secure Key, Intel Control-Flow Enforcement Technology, Intel Total Memory Encryption - Multi Key, Intel AES New Instructions, Intel Trusted Execution Technology, Execute Disable Bit, Intel OS Guard, Intel Boot Guard, Mode-based Execute Control (MBEC), Intel Stable IT Platform Program (SIPP), Intel Virtualization Technology with Redirect Protection (VT-rp), Intel Virtualization Technology (VT-x), Intel Virtualization Technology for Directed I/O (VT-d), Intel VT-x with Extended Page Tables (EPT).
