Server Technology C2S36TE-2CAF2M99 Smart Master Pro2 Hdot Outlets

Open Box products are in original manufacturer condition, include accessories, and most carry the manufacturer warranty. Manuals and software might not be included, but can usually be downloaded from the manufacturer. These items can be in the original manufacturer box or repackaged for protection during shipping.

Server Technology C2S36TE-2CAF2M99 Smart Master Pro2 36-Configurable Alt-Branch Hdot Outlets - 208V - 3BR - 30A - L6-30P

The Server Technology PRO2 Smart PDU provides local LED input current monitoring, allowing IT personnel to determine safe levels of loading on a per-phase basis while installing equipment into the rack/cabinet. The integral PIPS technology provides billing-grade accurate measurement of current, voltage, active power, apparent power, power factor, crest factor, and accumulated energy at the input. These power data points, along with temperature and humidity measurements (provided via optional probes), are accessible through the built-in Web and CLI interfaces as well as through SNMP. The PRO2 Smart Master PDU can be connected to as many as three (with optional module) PRO2 Smart Link PDU to extend the network access to the redundant or secondary power feed without the risks of a daisy chain linking configuration.

Model number	C2S36TE-2CAF2M99
Product Name	Server Technology C2S36TE-2CAF2M99 Smart Master Pro2 Hdot Outlets
Product Type	Hdot Outlets
Input Voltage	208 V
Input Plug Type	NEMA L6-30P
Input Current	30 A
Input Current Rated	24 A
Input Power Capacity	5 KW
Connector	(18) x IEC 60320/C13: North American Rating: ? 12A @208V L-L (15A Peak); (18) x Cx: North American Rating: ? 16A @208V L-L (20A Peak)
Operating Environment	32degF to 140degF / 0degC to 60degC | 8%RH to 90%RH non-condensing | 6,500ft/2km elevation
Storage Environment	-40degF to 185degF / -40degC to 85degC | 8%RH to 90%RH non-condensing | 50,000ft/15km elevation
Communications & Security	10/100/1000 Mbps Ethernet (RJ-45 connector), RS-232 serial (RJ-45 connector); Two (2) temperature/humidity sensor inputs (4P4C), Link port (RJ-12) - {also on Link PDU}; Web-browser GUI and command-line interface (CLI): HTTP/HTTPS, TLSv1.2, SSHv2, Telnet, SNMPv2c and v3 (GET, SET, Traps), IPv4 and IPv6, LDAPv3/LDAPS, TACACS+, RADIUS, FTP/SFTP
LED Current	+- 10% at 0.1 amp (0.3 - 9.9 amps) and 1 amp (> 9.9 amps) resolution
GUI Current	+- 1% at 0.01 amp resolution (above 0.25 amp)
Voltage	1% at 0.1 volt resolution (nominal +- 10%)
Active Power	+- 1% at 1 watt resolution
Apparent Power	+- 1% at 1 volt-amp resolution
Power Factor	+- 3% at 0.01 resolution
Crest Factor	+- 10% at 0.1 resolution
Energy	+- 1% at 0.1 kilowatt-hour resolution
Branch Measurement Accuracy	Current = +- 3% at 0.01 amp resolution (above 0.5 amp)
Branch Circuit Protection	UL489 Compliant 2-pole, 20A trip circuit breakers, three (3) branch, rating: ? 16A, 10 kAIC Interrupt Rating
Dimensions	70 tall x 2.2 wide x 2.5 deep inches / [1778mm x 56mm x 64mm]
