Server Technology PRO1 Primary PDU

Open Box products are in original manufacturer condition, include accessories, and most carry the manufacturer warranty. Manuals and software might not be included, but can usually be downloaded from the manufacturer. These items can be in the original manufacturer box or repackaged for protection during shipping.

Server Technology C1W24VT-5PPA17AC/C Switched PRO1 PIPS PDU - 24x IEC C13 Outlets - 415v - 3-phase - 30a

The Server Technology PRO1 Switched PDU provides control of outlet power and local LED input current monitoring, allowing IT personnel to determine safe levels of loading on a per-phase basis while installing equipment into the rack/cabinet. The integral PIPS technology provides billing-grade accurate measurement of current, voltage, active power, apparent power, power factor, crest factor, and accumulated energy at the input. These power data points, along with temperature and humidity measurements (provided via optional probes), are accessible through the built-in Web and CLI interfaces as well as through SNMP. The PRO1 Switched Primary PDU can be connected to as many as three (with optional module) PRO1 Switched Link PDUs to extend the network access to the redundant or secondary power feed without the risks of a daisy chain linking configuration.

Model Number	PRO1
Product Name	Server Technology PRO1 Primary PDU
Product Type	PDU
Network Monitoring	Gain access to valuable data through connections including HTTP(S), SSH, Telnet, SNMP, (S)FTP, SMTP, Syslog, LDAP(S), RS-232 serial, and more.
Star Multi-Linking	PRO1 provides the ability to link up to four power circuits using one IP address. Primary Expansion PDU provides backup power to network card.
IP Access, Security & Communications	Web, SSH, Telnet, SNMPv2c & v3, RS-232 serial, 10/100 Base T-Ethernet, LDAP(S), TACACS+, RADIUS, DHCP, & SMTP/email.
Per-Inlet Power Sensing	PIPS (Per Inlet Power Sensing) Monitors Current Load (A), Voltage (V), Power (W), Apparent Power (VA), Crest Factor, Power Factor, & Energy per inlet.
Outlet Control	On Switched PDUs, cycle power to individual outlets or groups of outlets to reboot servers, or power off unused receptacles.
High Temperature Rating	This product has been tested and approved for safe and reliable operation in 60 C data center environments.
Color-Coded Options	Select from six colors to designate PDU circuits in the data center black, white, red, green, blue, and yellow.
Hot-Swap Network Card	Network access is ensured when power is lost to the Primary unit with backup power provided by the Linked unit.
Temperature/Humidity Monitoring	Supports two external 10'' (3m) T/H probes. Receive SNMP-based alerts and email notifications.
Auto-Flip Current Display	Easy-to-read LEDs display current per phase to help prevent overloads and simplify three-phase load balancing in high density cabinets.
Branch Circuit Protection	UL 489, CSA C22.2 No. 5 & IEC/EN60947-2 Compliant 1-pole, 20A trip circuit breakers, six (6) branch, rating: 16A, 5 kAIC Interrupt Rating
High Retention Locking Outlets	PRO1 receptacles have high retention and are compatible with P-Lock type power cords.
Flexible Mounting	Includes standard button mounts along with provisions for custom mounting brackets.
Input Voltage (V)	415
Frequency	50/60 Hz
Input Plug	240/415V Wye 30A IEC 60309 3P+N+G 6Hr
Input Current (A)	30
Input Current Rated (A)	24
Input Power Capacity (kW)	17.3
Input Phase	3-Phase Wye (L-N)
Input Cord Location	Bottom/End
Outlet Form Factor	Conventional
Connector	Rating
(24) x IEC 60320/C13	North American Rating: 12A @240V L-N(15A Peak)
Branch Monitoring	Sense
Branch Overcurrent Protection	5 kAIC
Branch Overcurrent Protection Type	Circuit Breaker: 1-pole
Dual Input	No
High Retention Outlets	Yes
Input Current Display	Auto-Orient
Locking Outlets	Yes
Fast Movers	No
Mounting	0U Vertical
Outlet Monitoring	None
Physical	Dimensions: 69.0in tall x 1.75in wide x 3.5in deep [1753mm x 45mm x 89mm]
Environmental	Operating Environment: 32F to 140F / 0C to 60C
Communications & Security	10/100 Mbps Ethernet (RJ-45 connector), RS-232 serial (RJ-45 connector)
Certifications	North American:
Measurement Accuracy	Input Measurement Accuracy:
