Vertiv VP5N31A1 (Vertiv MNS5M1R6-12CF18-3TL6A0H10-S) Switched Rack PDU

Open Box products are in original manufacturer condition, include accessories, and most carry the manufacturer warranty. Manuals and software might not be included, but can usually be downloaded from the manufacturer. These items can be in the original manufacturer box or repackaged for protection during shipping.

Vertiv VP5N31A1 (Vertiv MNS5M1R6-12CF18-3TL6A0H10-S) Switched Rack PDU - 1U - Combination C13/C19 - 30 A - LCD Touch Screen Display - 10 Feet Cord - TAA Compliant - Black

The Vertiv Geist Switched RPDU VP5N31A1 is a 30A, 208V, 1U, horizontal rack power distribution unit with input power monitoring and outlet level switching. It has (12) Combination C13/C19 receptacles and a NEMA L6-30P plug providing 4.9kW of power capacity. This device allows you to remotely turn off receptacles to avoid accidental overloads and power cycle equipment to reboot unresponsive critical IT equipment. It is integrated with the Vertiv Geist Next-Generation IMD which displays power data via its 128x128 high-visibility LCD. It has an internal sensor that intelligently adjusts the orientation based on horizontal or vertical installation. This includes a redundant power-sharing port that connects two IMDs in the rack and provides backup power in case of power loss. Enhanced security with a secure boot is added to the device to help ensure data and operations are protected. The units are UL-listed, TAA-compliant, RoHS certified, and individually tested for functionality and reliability.

Model Number	VP5N31A1
Product Name	Vertiv VP5N31A1 (Vertiv MNS5M1R6-12CF18-3TL6A0H10-S) Switched Rack PDU
Product Type	PDU
Color	Black
Form Factor	Rack
Network (RJ-45)	Yes
Video Interfaces	Combination C13/C19
Camera Mechanical Design	Rack-mountable
Input Current	30 Ampere
Input Voltage	230 V AC
Input Voltage Range	200 V AC to 240 V AC
Output Voltage Range	200 V AC to 240 V AC
Plug Type	NEMA L6-30P
Power Rating (Watt)	4900 watt
Remote Outlet Switching	Yes
Cord Length	10 Feet
Management	DHCP, HTTP, HTTPS, IPv4, IPv6, LDAP, NTP, RADIUS, RSTP, SSH, SMTP, SNMP (v1/v2c/v3), Syslog, TACACS+
PDU Type	Switched
Phase	Single Phase
Protected Output Receptacles	12
Features	LCD Display, Touch Screen Display
Mounting Orientation	Horizontal
Protection Type	Overcurrent Protection
Height	1.7 inch
Height (Rack Units)	1U
Environmentally Friendly	Yes
TAA Compliant	Yes
Width	17 inch
Depth	12 inch
Weight	12 lb.
Also known as	Vertiv MNS5M1R6-12CF18-3TL6A0H10-S
